2J4715B-868 ISM screw mount Antenna IP69K

This low-profile antenna is designed for reliable performance in the 868 MHz ISM band, making it ideal for IoT, smart home, industrial, and asset tracking applications. Its robust screw mount design and IP69K/IP67 protection ensure durability in harsh environments. The antenna is ground plane independent and offers customizable cable and connector options to suit a wide range of installation requirements.

Connections

868MHz/Sigfox/LoRa/LPWA/RFID/ZigBee/ISM

Technical Specifications

Operating Temperature: -40 °C to +85 °C
Mounting: Screw Mount
Location: External
Type: Single

Connection 1 - 868 MHz ISM

Standards: ZigBee, ISM, SIGFOX, LoRa
Frequency: 863-870 MHz
VSWR: ~1.2:1
Efficiency (%): ~33.4
Peak Gain (dBi): ~2.6
Impedance (Ohm): 50
Polarisation: Linear
Max. Input Power (W): 25

Download Datasheet PDF
