2J7213B HDTV, DVBT, DAB screw mount Antenna IP67/IP69

This high-performance antenna is designed for reliable HDTV, DVBT, and DAB digital radio and television reception. Its robust construction and screw mount design make it ideal for outdoor installations, ensuring stable signal quality even in challenging environments. The antenna is suitable for a wide range of applications, including entertainment systems, marine, automotive, mobile, and leisure vehicles, as well as television and digital radio broadcast setups. With a ground plane dependent design and active gain, it delivers enhanced performance for demanding multimedia needs.

Connections

HDTV / DVBT
DAB (150-240 MHz)

Technical Specifications

Operating Temperature: -40 °C to +85 °C
Mounting: Screw Mount
Type: Single

Connection 1 - HDTV/DVBT Antenna

Standards: DAB, DVB-T
Frequency: 150-240, 440-870 MHz
VSWR: <3:1
Active Gain (dB): 23
Impedance (Ohm): 75
Power Consumption (mW): 390 max.
Voltage Range (V): 3.3-16
Polarisation: Linear
Radiation Pattern: Hemispherical

Download Datasheet PDF
